eBook GeoTol Pro 2020 Fundamentals Workbook

$70.00

Ebook format of the GeoTol Pro 2020 Fundamentals Workbook. Based on the latest ASME Y14.5-2018 Standards. Access is through our GeoTol U portal and is not available for download.

Description

The GeoTol Pro 2020 Workbook in electronic format. Based on the latest ASME Y14.5-2018 Standards. 400 pages, full color. Flips like a real book, access 24-7, wherever you have an internet connection. Hosted on our LMS system, Moodle. Access granted for 2 years.

View Outline

GeoTol Pro 2020 Workbook
Unit 1 Introduction – Symbols and Terms
Unit 2 Limits of Size
Unit 3 How the Geometric System Works
Unit 4 The Datum Reference Frame
Unit 5 The Three Product Plans and Position Inspection
Unit 6 Orientation Tolerances and the Hierarchy
Unit 7 Virtual Condition and Material Boundary Modifiers
Unit 8 The DRF II – Datum Targets and Irregular Surfaces
Unit 9 The DRF III – Advanced Concepts
Unit 10 Form Tolerances
Unit 11 Profile Tolerances
Unit 12 Position Tolerances
Unit 13 Coaxial Controls
Unit 14 Application Exercises
Appendix A Part 1 – Principle Changes and Additions in the ASME Y14.5-2018 from 2009

Part 2 – Principle Changes and Additions in the ASME Y14.5-2009 from 1994

Appendix B Differences between the ASME Y14.5 and ISO-GPS standards
